Technical Data
AEROTOP T20R-T35R
44
Heat pump type AEROTOP TR T20R T26R T32R T35R
Heating operation For A2/W35
Heating Capacity Qh KW
18.9 24.4 30.2 34.4
Power input Pel KW
5.8 7.4 8.8 9.2
Performance number EN14511 COP -
3.2 3.3 3.4 3.6
Cooling operation for A35/W18
Cooling Capacity Qc KW
20.2 30.6 34.7 36.6
Power input Pel KW
8.5 11.8 14 14.3
Condenser Scroll hermetically
Maximum current consumption Imax A
16 22 27 25
Start-up current with smooth starter VSA A
40 55 67.5 62.5
Current intensity with blocked rotor LRA A
99 123 127 167
Current connection V-f-Hz
400-3-50
Fuse WP A/T
32 40 40 40
Condenser, heater side Material: Chrome steel AISI 304, 1.4301
Hydraulic connections IG R"
1¼” 1¼” 1¼” 1¼”
Water content incl. connection hoses AEROTOP T l
4.9 4.9 5.7 5.7
Volume stream heating operation nom/min
1)
l/h
3700/1714 5850/2259 6280/2803 7300/2964
Pressure loss heating operation kPa
14.9/4.5 32.9/7.7 36.1/6.4 46.7/7
Minimum volume stream cooling operation (∆t= 5 K) l/h
3470 5260 5970 6300
Pressure loss cooling operation kPa
14 20.6 14.8 21.8
Max working pressure
p baar
10 10 10 10
Evaporator/fan
Volume stream m
3
/h
7'300 8'200 10000
11000
Available pressure
2)
Pa
149 198 225
313
Power consumption fan P kW
0.530 0.700 0.500
0.650
Maximum current consumption fan lmax A
1.8 2.5 2.5 2.5
Coolant -
R407C
Coolant filling AEROTOP TR kg
16 16 21 21
Coolant circuit oil - Ester Oil
Oil quantity l 4.1 4.1 4.1 4.1
Weight heat pump kg 375 392 460 468
Sound Level
3)
Outdoor installation
Standard configuration with Hoods
4)
Lwa dB(A)
66.0 70.0 67.0 70.0
Sound Level
3)
Indoor setup
Sound power level On suction Lwa dB(A)
65.0 67.0 66.0 70.0
On exhaust Lwa dB(A)
59.0 61.0 64.0 67.0
Inside Lpa dB(A)
59.0 59.0 63.0 68.0
1) Min: ∆t max= 10 K, with PHW-preparation ∆tmax = 5 K. (V' [l/h]= Qh[kW]/(4.18*∆t[K]*ρ[kg/l])*3600).
2) At maximum fan rotational speed.
3) Measuring according to DIN ISO 9614-2. Sound power level is a property of the source of noise and therefore dependent on the
distance; it describes the totality of the sound power of the corresponding source radiating in all directions. Information to deter-
mine the noise level see planning documents.
4) With Hl and HO Hoods
