Technical Data
AEROTOP T07R-T16R
43
Heat pump type AEROTOP TR T07R T10R T12R T14R T16R
Heating operation For A2/W35
Heating Capacity Qh KW
6.4 9.1 11.8 13.7 14.8
Power input Pel KW
2.0 2.8 3.4 3.9 4.1
Performance number EN14511 COP -
3.3 3.3 3.5 3.5 3.6
Cooling operation for A35/W18
Cooling Capacity Qc KW 6.7 9.7 11.9 15.3 15.6
Power input Pel KW 2.6 3.7 4.7 5.8 6.1
Condenser Scroll hermetically
Maximum current consumption Imax A 6.3 10 11 13 13.5
Start-up current with smooth starter VSA A 15.75 25 27.5 32.5 33.75
Current intensity with blocked rotor LRA A 40 50 66 74 74
Current connection V-f-Hz 400-3-50
Fuse WP A/T 16 16 16 20 20
Fuse WP with electrical insert A/T 20 20 20 25 25
Condenser, heater side Material: Chrome steel AISI 304, 1.4301
Hydraulic connections IG R"
1” 1” 1” 1” 1”
Water content incl. connection hoses AEROTOP T l
2.6 3 3.1 3.4 3.4
Volume stream heating operation nom/min
1)
l/h
1500/568 2100/835 2700/999 3070/1171 3100/1300
Pressure loss heating operation nom/min kPa 28.3/4.4 32.9/4.1 33/4.5 36.5/4.6 35.5/5.5
Minimum volume stream cooling operation (∆t= 5 K) l/h
1'150 1'670 2'050 3000 3050
Pressure loss cooling operation kPa
17.4 16.1 18.3 19.4 20.4
Max working pressure
p baar
3 3 3 3 3
Evaporator/fan
Volume stream m
3
/h
2'500 3‘300 5'300
6'300 6'800
Available pressure
2)
Pa
150 92 146
112 82
Power consumption fan P kW
0.035 0.100 0.100
0.170 0.210
Maximum current consumption fan lmax A
1.6 1.6 2.1 2.1 2.1
Coolant -
R407C
Coolant filling AEROTOP TR kg
5 7.5 9 9 9
Coolant circuit oil - Ester Oil
Oil quantity l 1.1 1.36 1.85 1.65 1.89
Weight heat pump kg 204 246 272 276 279
Sound Level
3)
Outdoor installation
Standard configuration
4)
Lwa dB(A)
62.0 65.0 61.0 66.0 70.0
Sound Level
3)
Indoor setup
Sound power level On suction Lwa dB(A)
53.0 56.0 54.0 59.0 61.0
On exhaust Lwa dB(A)
48.0 53.0 50.0 53.0 55.0
Inside Lwa dB(A)
50.0 54.0 55.0 60.0 60.0
1) Min: ∆t max= 10 K, with PHW-preparation ∆tmax = 5 K. (V' [l/h]= Qh[kW]/(4.18*∆t[K]*ρ[kg/l])*3600)
2) At maximum fan rotational speed.
3) Measuring according to DIN ISO 9614-2. Sound power level is a property of the source of noise and therefore dependent on the dis-
tance; it describes the totality of the sound power of the corresponding source radiating in all directions. Information to determine
the noise level see planning documents.
4) With Rain Guard
