Elcometer 224 User Manual

For a complete list of icons, see “Gauge Icons” on page 54 - 55
www.elcometer.com
R
en
10
b
a
c
d
e
f
g
h
i
q
r
t
s
k
j
l
m
n
o
p
Model
a
Green LED
BT
b
Battery Life Indicator
BT
c
Bluetooth On
T
d
Probe Scale
BT
e
Upper Limit On
T
f
Units of Measurement
(µm, mils, mm, inch)
BT
g
Batch Type
(normal, counted average)
T
h
Menu Softkey
BT
i
Display Softkey
BT
j
Red LED
(Reading outside limit)
T
k
Batch Name
(displayed when in batching)
T
Date & Time
(displayed when not in batching)
T
l
User Selectable Statistics
(4 rows)
BT
m
Reading Value
BT
n
Calibration Softkey
BT
o
Batch Softkey
BT
p
Bar Graph
(highest, lowest & average reading)
BT
q
Lower Limit On
T
r
Softkeys
BT
s
Run Chart
(last 20 readings)
T
t
Upper and Lower Limits On
T

Elcometer 224 Specifications

General

Brand	Elcometer
Model	224
Category	Measuring Instruments
Language	English
