Elcometer 224 - GAUGE OVERVIEW AND BOX CONTENTS; Gauge Overview; Box Contents

1 GAUGE OVERVIEW AND BOX CONTENTS
Packaging
The gauge is packed in cardboard packaging. Please ensure that this
packaging is disposed of in an environmentally sensitive manner.
Please Consult your Local Environmental Authority for further
guidance.
www.elcometer.com 4
R
en
Gauge Overview
Box Contents
1 LED Indicators - Red (left), Green (right)
2 Colour Screen
3 Multifunction Softkeys
4 On/Off Key
5 Separate Probe Connection
6 Internal Probe
7 Wrist Strap Connection
8 Battery Compartment (¼ turn open/close)
9 USB Data Output Socket (below cover)
§Elcometer 224 Surface Profile Gauge
§Calibration Test Foils; Nominal Values 125 &
a
500µm and Glass Zero Tile (Integral gauges)
§Test Certificate
§Wrist Harness
§Protective Case (Model B & T); Transit Case (Model T)
§1 x Screen Protector
a
§Probe Protection Cap (Integral gauges)
§2 x AA Batteries
§USB Cable & ElcoMaster™ 2.0 Software (Model T)
§User Guide
1
2
3
4
5
8
7
9
9
6
a
For separate gauges, the test foils, glass zero tile and probe protection cap are supplied with the separate
probe.
