Elcontrol NanoVIP3 - Technical Specifications

Man. NVIP3 – Rel 1.3 EN (UK)
- 56 -
8 - TECHNICAL SPECIFICATIONS
CASE:
Dimensions
203x116x53mm
Material
ABS with self-extinguishing V0 grade
Protection class
IP30
Weight
580 g
DISPLAY:
Dimensions
68x68mm
Type
128x128 FSTN Negative dot matrix graphic LCD
Backlight
White LED
Languages
English - Spanish - Italian - German - French
KEYPAD:
Type
Membrane keypad with 10 double-function keys
POWER SUPPLY:
External power supply
wall-plug switching; input 100-240VAC ±10% 47-63Hz with
interchangeable plug; output 7.5VDC - 12W
Battery pack
4 x AA NiMh 2100mAh
Duration of the battery charge
>24h
CONNECTIONS:
Voltages
Flexible cables L = 1.5m; 2.5mm
2
- 36A; 1000V CAT III - 600V CAT IV
with a 4mm, 90° protected blade plug connector, and a crocodile clip
with a 45mm opening (for sections up to 32mm)
Currents
Elcontrol Energy Net interchangeable amperometric sensors
FUNCTIONS:
Traditional electrical analisys
V, I, P, Q, S, F, PF, THD(V)%, THD(I)%, cosϕ, ϕ, peaks, minimums,
maximums, averages, max. demands, etc.
Neutral current
Measured
Three phase counters
kWh, kVArh, kVAh, both absorbed that generated
Counters for each single phase
kWh, kVArh, kVAh, both absorbed that generated
Cogeneration



Waveforms
V & I
Harmonics
Values and histograms up to the 50
th
order
Sags
Dips, swells & interruptions
Transients
Overvoltages & overcurrents
Unbalance



Test EN 50160



Inrush current



DC measures



K factor
Up to the 25
th
order
Alarms
Displayed
Alarms log
5 at display
Tariff bands
4
Energy costs



Measurament campaigns
unlimited, up to fill the memory card
CONNECTING SYSTEMS:
Single phase



Two phase



Three-phase, 3-wires, balanced



Three-phase, 3-wires, unbalanced



4-phase, 4-wires, balanced



4-phase, 4-wires, unbalanced



MEASUREMENTS:
Display refresh rate
1 sec.
Type of connections available
Three-phase (3 or 4 leads), two-phase (2 leads), and single phase
grid
Type of grid which can be connected
Low and medium voltage (LV and MV)
VOLTAGE (TRMS)
Channels
3 channels with common neutral + 1 independent, auxiliary channel
Input impedance
4 Mohm
