ELECTRO FREEZE Shake Model CS705
184592
12
5.9 Indicator- Light — “ADD MIX” 9
This light indicates the mix in the mix
hopper is at a low level and should be
refilled as soon as possible. Always main-
tain at least 2 inches (5.1 cm) of mix in the
hopper. For best operating results keep
hopper full.
When this float is mounted on the float
stem inside the hopper it automatically
senses the mix level. It activates the “Add
Mix” light
5.10 Mix Float (not shown)
5 Operator Controls — continued
5.8 Flavor Selection Buttons 8
T
hese push buttons are used to select the
flavor of shake to be dispensed. Press the
button for the desired flavor. Selection of
another button will cancel the previous
selection. ‘Vanilla’ provides product from
the cylinder only, with no added flavoring.
When ‘Chocolate’, Strawberry’, ‘Banana’ ,
or ‘Special’ are selected, that
corresponding pump will operate when
product is dispensed.
5.7 Rinse Switch 7
This momentary switch activates the rinse
water solenoid valve and the spinner motor
to rinse the mixing chamber between flavor
changes to eliminate flavor carryover.
