ELECTRO FREEZE Compact Series - Figure 2 Beater Shaft Assembly

ELECTRO FREEZE Model CS705
Use only original or authorized replacement parts with this freezer.
Use of unapproved parts will void warranty.
184952-01 3
Figure 2 Beater Shaft Assembly
Item Part No. Description
1.................HC118708 ....................Beater-Assy. Shake Short
2.................HC137362 ....................Blade-Scraper Shake Non Rev
3*................HC137593 ....................Washer-Double Shaft Seal
4*................HC160557 ....................Seal-Beater Shaft
* Can be ordered together
HC115525 ....................Seal-Assy. Shaft Double
SEAL-BEATER
SHAFT (CUP)
