ELECTRO FREEZE Model CS705
Use only original or authorized replacement parts with this freezer.
Use of unapproved parts will void warranty.
184952-01 5
Figure 4 Plunger Box
Item Part No. Description
1 ......HC150985 ...... Fuse-Fast AGC 1.0A 1/4 x 1-1/4
2 ......HC150984 ...... Breaker-Circuit 0.7A
3 ......HC121011 ....... Switch-Assy. Plunger (See Figure 5)
HC162303 ..... Spring-Plunger Rod
HC150456 ..... Switch-Snap Button
4 ......HC150452 ...... Breaker-Circuit 4.5A
5 ......HC150188 ...... Timer-DOB .5-60 Sec
6 ......HC150798 ...... Terminal-Strip
7 ......HC150381 ...... Relay-Flange Base w/Cover
8 ......HC150343 ...... Relay-Control Flange DPDT 24VAC
9 ......HC159235 ...... Switch-Toggle SPST
10....... HC150971 ...... Switch-Push DPDT MOM Black
11 .......HC150456 ...... Switch-Snap Button
12....... HC137760 ...... Rod-Plunger Switch (Actuator Button)
13....... HC150465 ...... Switch-Toggle 3PDT Center Off
14....... HC150971 ...... Switch-Push DPDT Mom Black
To Next Page
