ELECTRO FREEZE Shake Model CS705
184592
24
Priming the freezer removes all excess air
and sanitizer from the freezing cylinder and
sets the proper overrun for the first cylinder
of product. Always have clean, sanitized
hands when handling mix feed assemblies.
Handle only the top 1”. Make sure the mix
feet tube assembly and the inside of the
hopper cover are cleaned with sanitizer.
1. Wash and sanitize your hands and
forearms.
2. Place an empty container under the
dispense head. Install the mix feed tube
assembly in the closed position, as shown
in figure 8-2, into the mix feed drain in the
hopper. Pour a minimum of 2-1/2 gallons of
mix into the hopper.
3. Hold the plunger open and remove
the mix feed tube to allow mix to push out
the sanitizer. When pure mix flows from the
dispense head close the plunger.
4. When the mix stops bubbling install
the mix feed tube into the mix feed hopper
drain in the “open” position. Place the
selector switch to the “AUTO” position and
the syrup switch to the “ON” position.
Important:
Failure to completely remove sanitizer
or water from the freezing cylinder
before placing in “AUTO” will damage
the freezer.
5. Fill the hopper with mix and Install
the hopper cover.
6. During long idle periods, the regula-
tor should be closed — but remember —
when dispensing product, ensure that
the mix feed regulator is “OPEN” at all
times. If not open, the flow of mix will be
restricted. If lubricant blocks the inlet hole
in the tube it would also restrict the flow of
mix.
8.2 Priming
Pin is not in line with hole.
Look through top hole in
tube — you should see the
inner white plastic insert
tube (regulator) blocking
the opening.
Look through top hole
in tube — you should
see clear through.
Pin is in line with hole.
Figure 8-2 Mix Feed Tube Positions
