ELECTRO FREEZE Model CS705
Use only original or authorized replacement parts with this freezer.
Use of unapproved parts will void warranty.
184952-01 11
Item Part No. Description
1 ......... HC141185 ..........Panel-Rear
2 ......... HC140658 ..........Panel-Side RH
3 ......... HC150541 ..........Light-Indicator 28v ADD MIX
4 ......... HC196261 ..........Cover-Drip Tray
5 ......... HC196260 ..........Tray-Drip
5A....... HC140738 ..........Retainer-Drip Tray (Not Shown)
6 ......... HC121017 ..........Panel-Assy. Front 5 Flavor SH
6A....... HC159064 ..........Grommet-1.1 OD 7/8 GD x 5/8 ID (Drain Tube)(Not Shown)
7 ......... HC140659 ..........Panel-Side LH CS705
8 ......... HC141161 ..........Panel-Dispense 5 Flavor
9 ......... HC121018 ..........Trimstrip-Assy. Tapered
10......... HC120804 ..........Panel-Assy. Hopper & Top
11 ......... HC118691 ..........Cover-Assy. Hopper Insulate
12......... HC162200 ..........Cart-CS Stainless
HC162200-11 ... Latch-CS Cart
13......... HC155143 ..........Filter-22 x 19 x 3/8
Not Shown:
HC161300 ..........Switch-Level Float Sensor
HC161301 ..........Float-Level Sensor
HC139230 ..........Deflector-Panel (Left side top)
Hardware for Panels
Panel Screw
Nut-
Speed
Dispense
-Top
HC160025 n/a
Dispense
-Bottom
HC160076 n/a
Front HC160048 n/a
Rear HC160048 n/a
Side HC159219 n/a
Trimstrip HC160076 n/a
*N/A - Not Applicable
Figure 8 Panel View (Sheet 1 of 2)
CS705 Panel Decals & Labels
Part No. Description
HC165025 Beater Warning
HC165250 Cleaning Instructions
HC165093 Clear Overlay
HC164215 Flavor
HC165414 Nameplate-Electro Freeze
HC165126 Panel Removal
HC164220 Pump Potentiometer
HC164220-01 Pump Potentiometer Brown
HC164220-02 Pump Potentiometer Red
HC164220-03 Pump Potentiometer Blue
HC164216 Syrup Pump
HC164217 Trimstrip
HC169052 Ventilation 3 in.
