Electro-Voice EVID-S - EVID-S8.2 T Speaker 8 Cabinet 70;100 V

2. If 8 ohm mode is desired, remove the safety screw.
Safety screw (A) is shown in the previous step.
3. Attach the flush input cover (B).
B
EVID-S8.2T speaker 8” cabinet 70/100V
Configuring the transformer settings
To configure the transformer settings, do the following:
1. Select the desired power tap by using the rotary switch on the input panel.
+
A
2. If 8 ohm mode is desired, remove the safety screw.
Safety screw (A) is shown in the previous step.
4.3.3
EVID-S Surface Mount Loudspeakers
2017.08 | 01 | F.01U.345.360 Installation manual Electro-Voice
