Electro-Voice EVID-S - Wall Bracket Dimensions; EVID-S4.2;EVID-S4.2 T Wall Bracket Dimensions

Wall bracket dimensions
The wall bracket dimensions are not to scale and are for reference only.
EVID-S4.2/EVID-S4.2T wall bracket dimensions
+
-
15.5 mm
[0.6 in]
93.5 mm
[3.7 in]
15.9 mm
[0.6 in]
4x ∅4.5 mm
[4x ∅0.177 in]
117.0 mm
[4.6 in]
51.8 mm
[2.04 in]
∅8.0 mm
[∅0.315 in]
15.9 mm
[0.6 in]
7
7.1
