Electro-Voice EVID-S - Dimensions; Frequency Response and Impedance

Dimensions
140.0 mm
[5.51 in]
118.2 mm
[4.66 in]
184.0 mm
[7.24 in]
193.0 mm
[7.60 in]
Figure 6.1: EVID-S4.2/EVID-S4.2T dimensions
Frequency response and impedance
Figure 6.2: EVID-S4.2/EVID-S4.2T frequency response and impedance
6.1.1
6.1.2
EVID-S Surface Mount Loudspeakers
2017.08 | 01 | F.01U.345.360 Installation manual Electro-Voice
