Item Quantity Component
A 2 Speakers with speaker brackets attached
B 2 Wall mount brackets
C 2 Dust covers
D 1 Allen wrench
E 2 Grille logos (spare)
F 2 Safety screws for the mounting brackets
G 2 Safety screw caps for the mounting brackets
H 2 Covers for the locking bolt
I 1 Installation manual
J 2 Flush input covers
K 8 Screws for flush input covers
Table 3.2: Components list for speakers with transformer
A (x2)
B (x2)
D
C (x2)
E (x2)
F (x2)
G (x2)
H (x2)
I
J (x2)
K (x8)
Figure 3.2: Components list for speakers with transformer
EVID-S Surface Mount Loudspeakers
2017.08 | 01 | F.01U.345.360 Installation manual Electro-Voice
