Page 22
COMPONENT ACCESS AND REPLACEMENT
OVEN DOOR
All components and parts of the Oven Door assembly can be serviced or replaced. The door is not
available as a complete assembly. Service procedure is identical for Wave Touch and IQ Touch
models.
Gently close the door until it stops against the hinge
locks at approximately a 45 degree angle. (Photo C)
Photo C
To service the door begin by removing the door from
the range. Open the door fully and pull both hinge
locks down until they stop. (Photo A & B)
Photo A
Photo B
