Page 23
Make sure you have a rm grasp on the door and
continue closing the door to disengage the hinges
from the receivers. (Photo A)
When the door is about 4 inches away from being
completely closed it can be lifted off the range.
(Photo B)
Photo A
Photo B
To reinstall the door reverse the previous steps. Use your knee to stabilize and help guide the hinge
arms into the receiver slots in the frame. Once the door is secure in the frame open it fully and close
the hinge locks back in to their normal position.
To service or replace the door components remove
the door as previously described and place the door
on a protected work surface with the handle side
down.
Photo C
REMOVE
SCREWS
Begin disassembly by removing the two screws
at the top of the porcelain door liner (Photo C),
Door Disassembly
