RANGE TECHNICAL DATA
Relay Contacts
P4 (R)
to
P2 (O)
P6 (BK)
to
P10 (Y)
P6 (BK)
to
P8 (BL)
P6 (BK)
to
P12 (Y/BK)
J4/3 (BK)
to
J4/5 (V)
J4/3 (BK)
to
J4/6 (BR)
Component
L2 Out
Relay
Bake
Element
Broil
Element
Lower Oven
Element
Convection
Element
Door Lock
Motor
O
P
E
R
A
T
I
O
N
Bake / Time Bake
X X P
Convection Bake/Roast
X X X
Broil
X
Dehydrate
X X X
Bread Proof
X
Slow Cook
X X
Keep Warm (Upper Oven)
X X
Keep Warm (Lower Oven)
X
Bake (Lower Oven) *
X
Door Lock Motor
Locking/Unlocking
X
Clean
X X
X = Contact Closed P = Contact closed during Pre-Heat only
*Some Models
ES 610/615 Oven Relay Board Circuit Analysis Matrix - Dual Fuel Range
FREESTANDING ELECTRIC and DUAL FUEL MODELS
FUNCTION / RELAY EOC CONNECTOR / PIN# RELAY BOARD CONNECTOR / PIN #
/ K3 P9 / Pin 7 J5 / Pin 7
L2 Out / K2 P11 / Pin 4 J7 / Pin4
Broil / K4 P11 / Pin 1 J7 / Pin 1
Bake / K6 P11 / Pin 2 J7 / Pin 2
Convection Element / K10 P11 / Pin 5 J7 / Pin 5
Lock Motor / K12 P11 / Pin 6 J7 / Pin 6
Test for 3.3 VDC (+/- .5 volts) between GND on EOC circuit board and the indicated connector pin when the specied
function is activated.
EOC Signal Voltage Test Matrix - Dual Fuel Range
To Next Page
