Electrolux TT300 - Fuse Data: Electric Installation (750;75;650 EU;EEA); Electric Heating Fuse Data (EU;EEA); Steam;Gas Heating Fuse Data (EU;EEA)

Installation - electric, steam and gas heating
487 18 39 01 - 300/500/750 - GB
36
Only one
cable
for heat-
ing and
motor
Electric heating, fuse sizes, effects and voltages
400V *3NAC 50/60 Hz 31.3 kW 50A
400-440V 3AC 50/60 Hz 31.3 kW 50A
400V
*3NAC 50/60 Hz 37.3 kW 63A
400-440V 3AC 50/60 Hz 37.3 kW 63A
230-240V 3AC 50/60 Hz 31.3 kW 100A
230-240V 3AC 50/60 Hz 37.3 kW 100A
Voltage Total
output
Fuse
Within the EU and EEA - type 750/75/650
Only one
cable
for con-
trol and
motor
Steam and gas heating, fuse sizes, effects and voltages
400V *3NAC 50/60 Hz 2.0 kW 10A
400-440V 3AC 50/60 Hz 2.0 kW 10A
230-240V 3AC 50/60 Hz 2.0 kW 10A
230-240V 1AC 50/60 Hz 2.0 kW 10A
Voltage Total
output
Fuse
Electric installation
Electric
Steam
Gas
* If the machine is equipped with a zero voltage connection, this must always be connected
