Specifications, Functions and Features
0425052
Rev. E: 07/25/2018
Models: MVP-50P, MVP-50T, EDC-33P and EDC-33T-XX
MVP-50P and MVP-50T
Weight: 1.9 Lbs.
Environmental: Designed and Tested to TSO (DO-160E, See Enviornmental Qualification Form)
Software: Designed and Documented to TSO (DO-178B, Level C)
Minimum Performance Standards: TSO-C43c, TSO-C44c, TSO-C45b, TSO-C47a, TSO-C48,
TSO-49b and TSO-C55a.
Power Requirements: 7.5 to 30 Volts, 0.3 amps @ 24V (Typ), 0.6 amps @ 12 Volts (Typ).
USB Port: For USB Memory Stick use only.
Display: Active Matrix TFT, 262,144 colors, Sunlight readable
Backlight: Internal electric eye and external control line.
EDC-33P and EDC-33T
(S Version)
Weight: 1.0 Lb
Environmental: Designed and Tested to TSO (DO-160E, See Enviornmental Qualification Form)
Software: Designed and Documented to TSO (DO-178B, Level C)
Power Requirements: 7.5 to 50 Volts, 0.1 amps (Typ).
Accuracy all Functions: < 1% (Unless otherwise noted)
Input Configuration: EDC-33P: 1-Volt Channel, 1-Amp Channel, 1-Fuel Flow Channel,
6-Pressure Channels, 17-Temp Channels, 4-Resistive Fuel Level
Channels, 4-Capacitive Fuel Level Channels and 2-RPM Channels.
EDC-33T-XX: 1-Volt Channel, 1-Amp Channel, 1-Fuel Flow Channel,
9-Pressure Channels, 13-Temp Channels, 4-Resistive Fuel Level
Channels or 4-Capacitive Fuel Level Channels and 2-RPM Channels.
Note: Temp, Fuel Level and Pressure channels can be used to monitor other functions or annunciators.
