Elegoo PHECDA - Page 23

Ø Install the air tube holder
（PM3*8）2pcs
Ø Install the air nozzle
Ø Insert the air tube at the air tube end
Ø Insert the air tube at the air pump end
Finally, use a cable tie to fix the air tube and the laser device wire together
to prevent the air tube from being scratched during movement.
③
⑤
⑤
④
(M4*4 set screws) 1pc
①
②
20
