Air assist installation (optional)
Ø Parts list
Ø Accessories installation
Ø Remove the two screws on the lower left side of the
laser device.
Ø The window mirror of the laser head needs to be cleaned
regularly after long-term use, because after a long period
of cutting and engraving, the window mirror can cause
poor light output due to smoke corrosion.(Wipe the window
mirror with ethanol(≥75%))
Ø How to remove the window mirror:
The window mirror can be screwed out by putting the
wrench handle into the groove.
（PM3*8）2pcs
①-Air pump
②-Air nozzle
④-Pneumatic Fittings
⑤-Air tube
Cable tie*3
③-Air tube holder
(M4*4 set screws) 1pc
Maintenance Tips
19
