67
Page
Insulation to be fully closed
and sealed along length.
Bends where practical
should be insulated, by
cutting the insulation into
segments and taping
together.
Joins can be taped
together using aluminum
foil self adhesive tape.
Insulation may be fitted
prior and after the inline
powerflue fan.
Failure to fit insulation on the exhaust flue may result in
condensation failures with the appliance.
6. Connect power
lead to fan module.
Ensure lead is clipped
to support where
required.
Do not use connection to
support lead.
Connection to wall terminal
Loose fit connections (wall termination connections)
Insulation to be run for the first 3m from the appliance. For
flue runs shorter than 3m, insulation is not required.
