Element4 SKY Series - Technical Specifications and Data

30
Appendix F
INSTALLATION MANUAL |
Gas type » NATURAL GAS LPG
Country of use »
AT,BG,CH
DK,ES,FI
GB,GR,HR
IE,IT,LT
LV,NO,PT
RO,SE,SI
SK,TR
DE,LU
PL BE,FR DE NL
BG,DK,EE
FI,GB,GR
HU,HR,IT
LY,MT,NL
NO,RO,SE
SI,SK,TR
CZ,LT
NL,SK
AT,CH
CZ,DE
AT,BE,CH
CZ,DE,ES
FR,GB,IE
IT,NL,PT
SK,TR
Gas Category » I2
H
I2
E
I2
E+
I2ELL I2
L
/ I2
EK
I3
B/P
I3
p
I3
P
I3+
Unit G20 G20 G20/G25 G20/G25 G25/G25,3 G30/G31 G30 G31 G30/G31
Supply pressure mbar
20 20 20 / 25 20 25 30 50 28 - 30/37 30
Burner pressure mbar
16,0 16 16 / 19.5 16,0 19,5 28 28 28 28
Gross input kW
17,7 17,7 17,7 / 15,9 17,7 15,9 14,2 14,2 14,2 14,2
Net input kW
15,9 15,9 15,9 / 14,4 15,9 14,4 13,1 13,1 13,1 13,1
max. Heat output kW
13,7 13,7 13,7 / 13 13,7 13,0 12,5 12,5 12,5 12,5
min. Heat output kW
4,6 4,6 4,6 / 4,3 4,6 4,3 4,1 4,1 4,1 4,1
(Max.) Gas usage
m
3
/hr 1,67 1,67 1,67 / 1,8 1,7 1,8 0,35 0,35 0,35 0,35
kg/hr 1,18 1,18 1,18 / 1,33 1,2 1,33 0,64 0,89 0,64 0,64
NOx mg/kWh
input
<100 <100 <100 <100 <100 <100 <100 <100 <100
Pilot
440-1650-312 440-1350-271
Burnerinjection
380 (Main), 2x 320 (log) 1x 140 (Main), 2x 140 (log)
Type of ue C11 / C31 / C91
Additional electricity use
• At rated heat output el
max
9
-5
kW
• With minimal heat emission el
min
9
-5
kW
• In standby mode el
sb
9
-5
kW
Power requirement for the permanent pilot light
Power requirement for the permanent pilot
light (requirements applicable)
P
pilot
Does not
apply
Eciency (NCV)
• Eciency at rated heat output
η
th, nom
59 %
• Eciency at min. heat output (indicative)
η
th, min
58 %
Type of heat release / control room temperature (Select one)
• With electronic control of the room temperature plus week switch
Other control options
• Control of the room temperature with presence detection
• Control the room temperature with open window detection
• With the option of remote control
• With adaptive control of the start
• With limitation of the operating time
Glass size
• E4-16 724 x 1624 x 4 mm (WxHxT)
• E4-24 724 x 1227 x 4 mm (WxHxT)
• E4-34 724 x 830 x 4 mm (WxHxT)
F TECHNICAL DATA
The dataplate species for which type of gas, gas pressure and for which
country this appliance is intended. The nameplate is attached to a chain.
It must remain attached to the chain.
Note: Check whether the appliance is suitable for the gas type and gas
pressure on site.
