Elite CSW-200-UL Series User Manual

CSW-200-UL
1/2 hp Motor, 120 VAC, 4 Amp.
Maximum Gate Length – 18 ft.
Maximum Gate Weight – 600 lbs.
Maximum Pull – 125 lbs.
CSW-200-UL-ST
1/2 hp Motor, 120 VAC, 4 Amp.
Maximum Gate Length – 18 ft.
Maximum Gate Weight – 600 lbs.
Maximum Pull – 125 lbs.
CSW-200-UL-1HP
Two-1/2 hp Motors, 120 VAC, 7.9 Amps.
Maximum Gate Length – 20 ft.
Maximum Gate Weight – 1000 lbs.
Maximum Pull – 250 lbs.
CSW-200-UL-DM
Two-1/2 hp Motors, 120 VAC, 4 Amp.
Maximum Gate Length – 18 ft.
Maximum Gate Weight – 800 lbs.
Maximum Pull – 115 lbs.
ELITE RECOMMENDED SETUP
Recommended Gate Setup Configuration
Warning Signs Attached on Both Sides of Gate
Warning Sign Clearly
Visible on Operator
Gate Attachment Bar Must Go Completely
Across the Gate for Full Strength
4" Max. Width
Edge Sensors
Be sure to read and follow all Elite and UL instructions before installing and
operating any Elite products. Elite Access Systems, Inc. is not responsible
for improper installations or failure to comply with local building codes.
Pedestrians Must have a Separate Walkway!
9

Elite CSW-200-UL Series Specifications

General

Brand	Elite
Model	CSW-200-UL Series
Category	Gate Opener
Language	English
