33
ACCESS DOOR
UPHILL DRIVEWAY INSTALLATION
Possible
Special arm and hinges are required
Swivel Arm
Elite Part # Q103
Impossible
Gate hits driveway
Access Door - A generous allotment of space is allowed for external loop detectors and radio
receiver. For a secure attachment, velcro external loop detectors in place.
External Loop Detectors
Radio Receiver
W4
O
F
F
ON
