Elite CSW-200-UL Series User Manual

CONCRETE PAD AND GATE ARM ATTACHMENT
6"
Out
In
Post
Concrete Pad
Concrete Pad
Above
Ground
Below
Ground
Short Arm
Long Arm
Hinge
Center
14"
2"
24"
35.5"
46"
28"
25"
10"
29.5"
30"
28"
24"
Red Head Fastener
1/2" x 3 1/2"
Top View
Approximate Placement of Conduit
Electronic Box
W4
O
F
F
O
N
Important:
DO NOT weld any supports
to the chassis. It must be
allowed to “flex” during
operation.
5 1/4"
5 1/4"
3 7/8"
14"
3 5/8"
19"
10
Sample Installation
