ADJUSTMENT OF OUTPUT SHAFT
14
Tighten the Nut
Fit Pin in Slot
90°
Pull the short arm away from the gate.
NO slippage should occur.
If it does, go back and tighten the nut more.
Red handle
must be in
this position
Pull
Tighten
Handle
