Incorrect
Installation
Correct
Installation
Once the gate arm measurements are calculated:
Weld Completely Around the Rectangular Tubes
weld the bracket on the gate.
........then weld the shorter arm.
Weld the longer arm..........
GATE ARM INSTALLATION
13
