Elite CSW-200-UL Series User Manual

23
SOLENOID/MAGLOCK J3 CONNECTION
CENTER SAFETY EXIT
CENTER SAFETY EXIT
FIRE
DEPT.
13
STRIKE
OPEN
RADIO
RECEIVER
TIMER
SYSTEM ON
EXIT
LOOP
ALARM
SENSOR
REVERSE
SENSOR
OPEN
STOPCLOSE
SAFETY
LOOP
CENTER
LOOP
GATE
LOCKED
60
POWER
OVERLOAD
OFF
W4
OPEN LEFT
DC-BACKUP
ALARMSENSOR
OPEN RIGHT
3
SENSORS
RESET
MOTOR
13
13
COMMAND
PROCESSED
ON
GB
MS LINK
A
MADE IN USA
Connection of a Solenoid or Magnetic Lock can be made
using the J3 plug and three wires supplied with the unit.
J3
2
8
10
9
7
1
3
Insert 2 supplied wires
into J3 plug (#3 and #7)
(Motor Harness)
#3 Normally Closed
#7 Common
Plug-In
Transformer
Solenoid Lock
Solenoid Lock
Ground
Ground
Power
Wire Nut
J3
2
8
10
9
7
1
3
Magnetic Lock
Insert 2 supplied wires
into J3 plug (#7 and #8)
(Motor Harness)
#7 Common
#8 Normally Open
Plug-In
Transformer
Magnetic
Lock
Ground
Ground
Power
Wire Nut
J3
9
2
8
10
7
1
3
Normally Closed
Wire Harness
Normally Open
Common
Relay Contact Rating
0.5 A - 125 VAC
1 A - 24 VDC
