COMPACT INSTALLATION
12
4"22"
4" 20"
24"
36"
10"
Long Arm
Cut Cut
Short Arm
Cut
Follow the exact measurements, then cut the standard arm to meet the shorter measurements.
Compact Installation Only!
Do Not Use These Measurements for a Standard Installation.
Gate ClosedGate Open
Hinge Center
9"
2"
33"
25.5"
23"
20"
to
32"
26.5"
20"
Minimum
Width
