3
Machine Parts and Functions
Part Names
1. Top cover
2. Design chart
3. Spool pin
4. Spool holder, large
5. Bobbin winder cutter
6. Bobbin winder spindle
7. Bobbin winder stop
8. LCD touch screen
9. Start/Stop key
10. Bobbin cover plate release button
11. Extension table (accessory storage box)
12. Bobbin cover plate
13. Needle plate
14. Built-in needle threader
15. Thread cutter and holder
16. Face plate
17. Thread tension dial
18. Thread take-up lever
19. Thread guide slit
20. Needle clamp screw
21. Needle
22. Presser foot
23. Carrying handle
24. Presser foot lever
25. Carriage
26. Machine socket
27. Power switch
28. Card eject button
29. PC design card (optional)
30. PC design card slot
31. Flywheel (always turn towards you)
1
2
3
4
6
5
7
8
12
11
10
9
15
14
13
17
16
18
22
21
20
19
27
26
25
24
30
29
28
31
23
