ELNA 8200 - Turning On the Power Switch

8
Edit
Mode
1 2 3 4
5 6 7 8
Designs
Hoop Size A(F): 126 X 110 mm
A Z
IMPORTANT:
Before turning on your machine, clear
your table surface of anything that might
obstruct the carriage movement. If your
machine is in a cabinet, check that the
machine is even or above the cabinet
surface. (The carriage could possibly hit
the cabinet and disturb the sewing result.)
TURN ON THE POWER SWITCH.
NOTE: After turning on the machine there is
approximately a six second delay before the LCD
Touch Screen becomes visible. (This is the
required boot up time and is not a malfunction.)
q Start/Stop Key (changes color to indicate
function)
Press this (green) key to start the machine.
When the machine is running, press this (red)
key to stop machine.
NOTE: The Elna 8200 is equipped with a
safety feature that will automatically shut down
the machine to prevent overheating if it is
running overloaded. Follow the instructions
that appear in the LCD touch screen should
this occur.
q
