ELNA Lock L4 - Main Parts Identification

PARTIES
ESSENTIELLES
1 Poign6e
2
Rdglage de
la
pression
du
Pied
3
Tension
aiguille
gauche
(rouge)
4 Tire-fil aiguille
5 Couvercle
de lampe
6
Tension
aiguille
droite
(bleu)
7
Couvercle
latdral
8
Tige
guide-fil
9
GuideJil sup6rieur
10
Tig.
porte-bobine
11 Support-bobine
12
Base support-bobine
1 3 Base
tige
porte-bobine
lat6rale
14
Guide-f il tension
boucleur
'l
5
Tension
boucleur supdrieur
(jaune)
16 Tension
boucleur infdrieur
(vert)
17 Vo
lant
18
Couvercle
frontal
19 lnterrupteur
principal
20 Pddale
MAIN
PARTS
1 Carrying
grip
2
Foot
pressure
control
3 Left
needle thread
tension
(red)
4
Needle thread take-up
lever
5 Lamp
cover
6
Right needle thread
tension
(blue)
7 Side cover
8
Thread
guide
pole
9
Upper thread
guide
10
Spool
pin
11 Spool
holder
12 Spool
pin
base
13
Side spool
pin
base
14 Looper
tension thread
guide
15 Upper
looper thread tension
(yellow)
16 Lower
looper thread
tension
(green)
17
F
lywheel
18
Front cover
19
Main switch
20
Foot control
