Elo TouchSystems ET1587C User Manual

- 99 -
D609 DIODE 1A/600V T PR1005 372153100600
D301 DIODE 1A/1KV T FR107/PR1007 372153101000
D617 DIODE HER304 3A/300V KINK P=20 372201300325
D615 DIODE HER305 3A/400V KINK P=20 372201300425
D621 DIODE 3A/800V KINK P=20 UF3006 372201300824
D622 DIODE 3A/1KV KINK P=20 UF3007 372201301024
D517 DIODE 1A/100V T HER102/UF1002 372203100100
D616,D624 DIODE 2A/400V T HER205/UF2004 372203200400
D608 DIODE 2A/800V T HER207/UF2006 372203200800
D601 DIODE BRIDGE PBL406/KBL406(4A/800V) 373000400800
LED1 LED D=3mm GREEN L-34GD 373502100300
D605 DIODE ZENER HITACHI 1/2W HZ4C3 DO-35 T 375003043300
D610A,R804 DIODE ZENER 1/2W HZ5C2 5.0V-5.2V T 375003053200
D510 DIODE ZENER 1/2W HZ15-2 T 375003150200
D619A DIODE ZENER 1/2W HZ20-3 20.2-21.1 T 375003200300
D515 DIODE ZENER 1/2W HZ36-2 T 375003360200
D504 ZENER DIODE 1W Z150A 150V 10% T 375503015100
U301 IC TDA8172 vertical process 381300017210
U201 IC TDA9113 381400011310
U602 IC UC3842AM 8 382500084227
U501 IC HA17812 3 382600081201
Q505 IC TL431 382660043144
U603 IC LM2940 3 382700094005
U102 IC AT24C04 8 384300040425
U103 IC WT6804 16 384300080416
U101 MASK MCU ELO UD7/TE6/ETx REV1.0 384915930116
RL501 RELAY 1P2T 12V JS1-12V AJS-1311 NAIS 432001200700
RL601 RELAY 2P1T 12V FTR-F4AK012T 432002101000
PCB MAIN CEMI-1 T1.6/1oz 246x249mm REV.01 ET15/17 441000470100
U101A IC SOCKET 40PIN 2.54mm D=15.24 450050404000
F601A CLIP FUSE 5X20mm t=0.4mm 450065200200
TB2 GT PIN R=1.56mm l=13mm 452001561300
R525A GT PIN R=2.36mm L=20mm 452002362000
R525B GT PIN R=2.36mm L=20mm 452002362000
T12 BASE PIN 2.0mm 2PIN 452072000200
T10 BASE PIN 2.5mm 2PIN 452102500200
T3 BASE PIN 2.5mm 5PIN 452102500500
T8 BASE PIN 2.5mm (NARROW) 3P 452142500300
T7 BASE PIN 5-7.5mm 2PIN A1561WV2-2P 452205750200
T5 BASE PIN 8-10mm 4PIN JS-1122-4 452258100400
DOWNLOAD PIN HEADER 2.54mm 2PINX1ROW 452802500200
T11A PIN HEADER L=4.0mm 2.54mm 6PINX1ROW RA 452862500600
T9A PIN HEADER L=4.0mm 2.54mm 13PINX1ROW RA 452862501300
T4A BASE PIN 2.0mm 6PIN RA 453012000600
F601 FUSE GLASS TUBE 5TT3 BEL 3A 250V S-B 5*20 UL/CSA 471100030000
F602,J21 FUSE PICO 2A 125V F-B 251 471503020000
