- 100 -
X101 CRYSTAL 12MHZ (HC-49/U) 473000120000
U301T SILICON INSULATOR TO-220 13mmX18.5mm 475000100100
Q602P SILICON RUBBER TO-2025A 20mmX25mmx0.45mm 475000200200
Q602N TRANSISTOR COVER TR-09 475050000100
W502 WIRE 1500#18 BLK SRA/ST0(SLEEV) L=180mm 512006401800
G2 WIRE SVF1/1032#22 WHITE L=330 523018593300
S101 WIRE ASSY AC CONNECTOR 3PIN ELO 531000301100
T6 WIRE ASS'Y 2651#28 2mm-6/2mm-6 L=240mm 531000601200
T4 WIRE ASS'Y 2651#28X6C 6P-6P(3,4 CROSS)L=1000mm 531000601900
T2 WIRE ASSY L=330mm 2mm-9/2mm-9 2651#28+CORE 531000900900
W202
SIGNAL CABLE
UL20279X13C
DSUB-15/XHP-5-7 L=280mm 531310200300
T1 JUMPER WIRE PITCH=5mm 531400005000
D803,D804,J01,J13, JUMPER WIRE PITCH=7.5mm 531400007500
J15,J16,J31,J37,J38,
J39,J40,J42,J43,J47,
L611,R148,R149,R153,
R574,R803
J02,J06,J10,J11,J17, JUMPER WIRE PITCH=10mm 531400010000
J18,J19,J22,J25,J26,
J29,J30,J32,J33,J48,
L101,L508,R613,R624
J12,J20,J23,J24,J34, JUMPER WIRE PITCH=12.5mm 531400012500
J36,R506,R534
J04,J07,J08,J09, JUMPER WIRE PITCH=20mm 531400020000
J14,L504
R620A TUBE HOT-SHRINK UL/CSA D=9X0.25mm L=30mm 531509003000
G2A,G2C CABLE TIE PLT1M L=100mm 7130K12 532000001000
ET17F M/B RIVET ASSY ET17F 571717303000E
U301P TRANSISTOR WASHER PIN GOOD 604S 712000300101
5S01 BRACKET BACK (ELO) 720114300103
5S05,5S06 BRACKET FOOT (ELO) 720114400301
5S07 BRACKET FBT (ET1) 720120500101
5S02 HEAT SINK SIDE (L) (ELO) ET17/19 730102500101
5S03 HEAT SINK SIDE (R) (ELO) 730102500401
Q516N HEAT SINK 60X24X30.5 18mm 730401900101
5S02M,5S03M SCREW CPM 3.0x8 Zn-Cc 771106050201
S101N SCREW CPTTB 4X8 Zn-Cc 771317050201
5S01N,5S07M, SCREW CPTSPB 3.0x8 Zn-Cc 771376050201
Q516M,W202N
U301M SCREW CPTSPB 3.0x12 Zn-Cc 771376070201
5S07N SCREW CTTWC 4.0x10 Zn-Cc 773457060201
5S01M,Q501M, SCREW CTTWE 3.0x8 Zn 773656050201
Q508M,Q509M
Q602M SCREW CTTWE 3.0X14 Zn 773656080201
