Elo TouchSystems ET1587C User Manual

- 97 -
ET1787C-4SWA-1-BAL
CIRCUITREF DESCRIPTION PART NO.
V501B COIL DEGAUSSING 2UEW 17 321400001207
321400001200
321400001213
V501C COIL ROTATION 300 TURNS L=200mm 321760000200
JA01 JUMPER HOUSING 2PIN 451050000100
PFC CTRL PCBA 435030-000 BALLY IT SERIAL ET 474000000600
5S04M GASKET 20X20X20 474400000300
W100 WIRE SRA 1015#22 BLK L=60mm 511165300600
W205 WIRE ASSY L=820mm SIGNAL-POWER CABLE 531000006200
T10A WIRE ASSY 1007#26 2.5mm 2P-4P L=380mm 531000202900
V501D WIRE ASSY 1015#22 SGF-STO L=170/110+SLEEVE 531000203300
V501CA,V501CC CABLE TIE PLT1M L=100mm 7130K12 532000001000
W205A CABLE TIE PLT1M L=100mm 7130K12 532000001000
V501A CRT GROUNDING WIRE 0.12/64 1015#22 ET17 532500005500
ET17 M/B RIVET BALLY ASS ET17 571717303000G
ET17 CRT iTOUCH ASSY ET17 571717402000A
ET17/19 CRT BOARD ASSY ET17/19 571909304000A
6F12 MINI BEZEL ET17 (NEW) 710102500101
6F08S KNOB ET17 ATRONIC 711102000101
6F04N,6F05N PCB SUPPORT R0180L2000 PINGOOD SCB-5 (ET1) 711901900101
T10B MOVABLE TIE PINGOOD (BST-6A) 712100800101
6F02R MOUNTING PURSE LOCK PINGOOD AB-16 712301200101
6F04 BRACKET BACK COVER ET17 BALLY 720129100101
6F03
BRACKET MAIN BOARD
COVER
ET17 BALLY 720129200101
6F02 BRACKET RIGHT ET17 BALLY 720129300101
6F01 BRACKET LEFT ET17 BALLY 720129400202
6F05 MOUNTING BRACKET ET17 BALLY 720133900101
V501P CAUTION LABEL 25KV 740202400101
6B01M HI POT LABEL 740202700101
WARNING LABEL D.I FOR CARTON (ELO) 740203200101
V501Q CRT LABEL FOR CPT ASAHI 740402400101
6F08T VR LABEL ET1 KNOB 740402900101
BLANK B/C LABEL T=0.05 76X57.6 741200700101
RIBBON RICOH B-110A 110mmX300M 741300200101
6F12M WIPER BLADE EXTRUEDE ELO 700307 760400100101
6F01P,6F02P SCREW CPM M6X16 Zn 771109090101
6F04M SCREW CPMSP M4.0X8 Zn-Cc 771177050201
6F01S,6F02S SCREW CPMSP M4.0X10 Zn-Cc 771177060201
6F01R SCREW CPMSP M4X16 Zn-Cc 771177090201
6F02T,6F02U SCREW CPTSPB 3.0x8 Zn-Cc 771376050201
W204M SCREW BPM 4-40-3/16 Zn DB9 771703230301
6F01N,6F02N SCREW IOHM M4X10+M6X15 Zn 775117060101
6F03M NUT M3.0 3.0x0.5 Zn-Cc 780203010201
6F03N NUT M4 4.0X0.7 HEX Zn 282804 780204010101
6F01Q,6F02Q WASHER P6.4Xd9.5X7.9 Ni 790100460101
