Elo TouchSystems ET1587C User Manual

- 98 -
6F02V POP RIVET 1/8" 790800050501
6F01M,6F02M WASHER 16X9.5X6.1 791200020101
1P21 PE BAG 900x500x440x0.03t 810202500101
1P11B DRIER SILICA GEL ELO 15 (40g) 810400300101
1P01 EPE FOAM (L) ET17 BALLY 810704400101
1P02 EPE FOAM (R) ET17 BALLY 810704500101
1P22 ZIP BAG R0273A14 210X295X0.04t 811200400101
1P11 CARTON ET17 BALLY/ATRONIC 820108800101
V501E,V501F TAPE MYLAR 3M#898 19mmX50M 820300400101
6F12N BEZ-GASKET ET17/19/21 820305100101
END UNIT LABEL (INNE) 820600500101
BLANK LABEL (50X35) 820604200101
BLANK BARCODE LABEL ELO 100X100 820606200101
1P06 PALLET WOODEN 1145X1130X130mm 821601600101
GLUE HOT MELT CLEARSTICK ELO (160108) 830100300101
LOCTITE ELO (262) 830100400101
6F12 FLUOROSYL 998307 FSD2500-16 ELO 830200300101
571909304000A (ET17/19 CRT BOARD ASSY)
CIRCUITREF DESCRIPTION PART NO.
R711,R712,R713,R714, RES CF 1/8W 100ohm J T 211003010100
R736
R710,R737 RES CF 1/8W 1K J(+/-5%) T 211003010200
R707,R735 RES CF 1/8W 10K J(+/-5%) T 211003010300
R708,R709,R722,R723, RES CF 1/8W 220ohm J(+/-5%) T 211003022100
R724
R729,R730,R731 RES CF 1/8W 220K J T 211003022400
R704,R705,R706 RES CF 1/8W 330ohm J T 211003033100
R726,R727,R728 RES CF 1/8W 56ohm J T 211003056000
R701,R702,R703 RES CF 1/8W 75ohm J T 211003075000
R738 RES CF 1/4W 100ohm J T 211103010100
R732,R733,R734 RES CF 1/4W 56ohm J T 211103056000
R742 RES CF 1/2W 100K J T 211203010400
R741 RES MOF 1W 3.3ohm J 12.5 212501033800
C704 CAP ELEC 100uF M 10V 105 TAPING 261201310100
C708 CAP ELEC 22uF M 10V 105 T 261201322000
C710 CAP ELEC 10uF M 50V 105 T (20%) 261205310000
C722,C727 CAP ELEC 2.2uF M 100V 105 TAPING 261208322800
C716,C717,C718 CAP ELEC 1uF M 100V 105 NK T 261328310800
C709 CAP CERAMIC 100PF K 50V Y5P T 272001310100
C705 CAP CERAMIC 220PF K 500V Y5P T 272004322100
C724 CAP CERAMIC 560PF K 500V Y5P T 272004356100
C711,C719,C720,C721, CAP CERAMIC 0.01uF M 500V Z5U T 272104310300
C726
C723 CAP CERAMIC 0.01uF M 1KV Z5U 7.5 20% 272105110300
C707,C712,C713,C714, CAP CERAMIC 0.1uF Z 50V Y5V T (20%) 272201310400
C715,C725
