Elo TouchSystems ET1587C User Manual

- 99 -
C701,C702,C703 CAP PLASTIC 0.022uF J 50V PEI T 281001322300
L704,L705,L706 COIL PEAKING 0.22uH K T 323053022900
D701,D702,D703,D704, DIODE FDH400.TR D0-35 370503040000
D705,D706
D707,D708,D709,D711 DIODE 1N4148(1A/75V) T 371303107500
U701 IC LM1269 NS 381000026905
U703 IC LM2469TA 381100046905
U702 IC LM2480 NS 381100048005
U704 IC L7805CV 3 382600080510
PCB NECK CEM-I T1.6/1oz L82xW90mm FOR ET17 /19 441100310100
CRTA SOCKET CRT ISDW01S 01S44C INCHANGE 450010001700
G2 GT PIN R=1.56mm l=13mm 452001561300
T704 GT PIN R=2.36mm L=14mm 452002361400
T701 BASE PIN 2.5mm 7PIN R/A 452112500700
T703 BASE PIN 2.0mm 6PIN RA 453012000600
T702 BASE PIN 2.0mm 9PIN RA 453012000900
C728,K701,K702,K703, SPARK GAP 1.2KV 473500312200
K704
J702,J703,J710 JUMPER WIRE PITCH=7.5mm 531400007500
J701,J705,R719,R720, JUMPER WIRE PITCH=10mm 531400010000
R721
J706,J707,J708,J711 JUMPER WIRE PITCH=12.5mm 531400012500
J704 JUMPER WIRE PITCH=15mm 531400015000
J709 JUMPER WIRE PITCH=20mm 531400020000
ET17/19 CRT BOARD ASSY ET17/19 571909304000A
5S04 VIDEO SHIELDING GAME 720305200101
U703N HEAT SINK 60LX24WX30.5H 13mm 730401900301
U703M SCREW CTTWE 3.0x8 Zn 773656050201
571717402000A (ET17 CRT iTOUCH ASSY)
CIRCUITREF DESCRIPTION PART NO.
V501 CRT (Asahi) 0.27mm M41AGE93X46C(L) 411702702004
V501E ALU TAPE 3cmX20cm ELECTRIC 474363002000
WIRE ASSY ELO012526 ET17 531001202700
ET17 CRT iTOUCH ASSY ET17 571717402000A
ADHESIVE DOUBLE TAPE ELO W=3.14mm L=33M/R 820303300101
GEL 602-GEL ELO 10ml 830100200301
UV GLUE Elo (6-20288) 830101400101
UV INK 160173 ELO (M16979-05-N) 700g 830200100101
571717303000G (ET17 M/B RIVET BALLY ASS)
CIRCUITREF DESCRIPTION PART NO.
R220,R502,R623 RES CF 1/8W 10ohm J T 211003010000
R134,R135,R136,R137, RES CF 1/8W 100ohm J T 211003010100
R146,R147,R223,R224,
R225
