- 116 -
C708 CAP ELEC 22uF M 10V 105 T 261201322000
C710 CAP ELEC 10uF M 50V 105 T (20%) 261205310000
C722,C727 CAP ELEC 2.2uF M 100V 105 TAPING 261208322800
C716,C717,C718 CAP ELEC 1uF M 100V 105 NK T 261328310800
C709 CAP CERAMIC 100PF K 50V Y5P T 272001310100
C705 CAP CERAMIC 220PF K 500V Y5P T 272004322100
C724 CAP CERAMIC 560PF K 500V Y5P T 272004356100
C711,C719,C720,C721, CAP CERAMIC 0.01uF M 500V Z5U T 272104310300
C726
C723 CAP CERAMIC 0.01uF M 1KV Z5U 7.5 20% 272105110300
C707,C712,C713,C714, CAP CERAMIC 0.1uF Z 50V Y5V T (20%) 272201310400
C715,C725
C701,C702,C703 CAP PLASTIC 0.022uF J 50V PEI T 281001322300
L704,L705,L706 COIL PEAKING 0.22uH K T 323053022900
D701,D702,D703,D704, DIODE FDH400.TR D0-35 370503040000
D705,D706
D707,D708,D709,D711 DIODE 1N4148(1A/75V) T 371303107500
U701 IC LM1269 NS 381000026905
U703 IC LM2469TA 381100046905
U702 IC LM2480 NS 381100048005
PCB NECK CEM-I
T1.6/1oz
L82xW90mm FOR ET17 /19 441100310100
CRTA SOCKET CRT ISDW01S 01S44C INCHANGE 450010001700
G2 GT PIN R=1.56mm l=13mm 452001561300
T704 GT PIN R=2.36mm L=14mm 452002361400
U704 BASE PIN 2.5mm 2PIN 452102500200
T701 BASE PIN 2.5mm 7PIN R/A 452112500700
T703 BASE PIN 2.0mm 6PIN RA 453012000600
T702 BASE PIN 2.0mm 9PIN RA 453012000900
C728,K701,K702,K703, SPARK GAP 1.2KV 473500312200
K704
J702,J703,J710 JUMPER WIRE PITCH=7.5mm 531400007500
J701,J705,R719,R720, JUMPER WIRE PITCH=10mm 531400010000
R721
J706,J707,J708,J711 JUMPER WIRE PITCH=12.5mm 531400012500
J704 JUMPER WIRE PITCH=15mm 531400015000
J709 JUMPER WIRE PITCH=20mm 531400020000
ET17 CRT BD
ATRONIC ASSY
ET17
571717304000
A
5S04 VIDEO SHIELDING GAME 720305200101
U703N HEAT SINK 60LX24WX30.5H 13mm 730401900301
U703M SCREW CTTWE 3.0x8 Zn 773656050201
571717305000A (ET17 PFC BOARD ASSY)
CIRCUITREF DESCRIPTION PART NO.
R605 RES CF 1/8W 10ohm J T 211003010000
R606 RES CF 1/8W 10K J(+/-5%) T 211003010300
R603 RES CF 1/8W 15K J T 211003015300
