Elo TouchSystems ET1587C User Manual

- 117 -
R607 RES CF 1/8W 22K J T 211003022300
R610 RES CF 1/8W 5.6K J T 211003056200
R609,R609A, RES CF 1/2W 470K J T 211203047400
R611,R611A
R612 RES MOF 2W 0.47ohm J 15 212601047900
R602A NTCR 3A 5ohm SCK053 231103050800
C606 CAP ELEC 10uF M 50V 105 T (20%) 261205310000
C608A CAP CERAMIC 100PF K 50V Y5P T 272001310100
C605A CAP PLASTIC 0.68uF J 400V MEF 20 281406168400
C608 CAP PLASTIC 0.1uF J 63V MEB T 281502310400
C607 CAP PLASTIC 0.022uF J 63V MEB T 281502322300
T602 PFC TRANSFORMER PFC ET17 331650000500
Q601 TRANSISTOR SSS6N60A 361550066000
D604 DIODE 1A/400V T FR104/PR1004 372153100400
D607 DIODE 3A/800V KINK P=20 UF3006 372201300824
U605 IC L6561 380500056110
PCB CEM-1 T1.6/1oz 52.5x81mm PFC BOARD ET17 441740000300
T13A
PIN HEADER
L=4.0mm
2.54mm 9PINX1ROW RA 452862500900
J35,R604,R608 JUMPER WIRE PITCH=7.5mm 531400007500
L605 JUMPER WIRE PITCH=10mm 531400010000
ET17 PFC BOARD ASSY ET17 ATRONIC 571717305000A
PCB HINGE PINGOOD BH-7 711902800101
Q601Q HEAT SINK 40LX24WX30.5H 730402700101
Q601M SCREW CTTWE 3.0x8 Zn 773656050201
