Elo TouchSystems ET1587C - Page 19

- 18 -
Table 1 for mode setting
Model : ET15
Mode Card Item Freq. H. KHz Freq. V. KHz Resolutions
1 VGA 31.5 70.08
640 ×400
2 VGA 31.5 60
640 ×480
3 VGA 31.5 70.08
640 ×350
4 VESA 53.674 85.061
800 ×600
Model : ET17 & ET19
Mode Card Item Freq. H. KHz Freq. V. KHz Resolutions
1 VGA 30 50
536 ×420
2 VGA 30 60
536 ×420
3 VGA 31.5 70.08
640 ×400
4 VGA 31.5 60
640 ×480
5 VGA 31.5 70.08
640 ×350
6 VESA 53.674 85.061
800 ×600
7 VESA 68.667 84.997
1024 ×768
8 VGA 31 60
640 ×480
9 SVGA 37 60
800 ×600
10 VGA 31 60
640 ×480
Note:
1. Mode 1~2 for ET17 and ET19 Bally models only.
2. Mode 7 for ET17 and ET19 models.
3. Mode 8~10 ET1988C-4SWA-1-SEGA TPS model.
