Elo TouchSystems ET1587C User Manual

- 191 -
C504,C617 0.0022uF J 50V PEI T CAP PLASTIC 281001322200
C539,C541,C801 0.022uF J 50V PEI T CAP PLASTIC 281001322300
C518 0.0033uF J 50V PEI T CAP PLASTIC 281001333200
C102,R140 0.0047uF J 50V PEI T CAP PLASTIC 281001347200
C308 0.0068uF J 50V PEI T CAP PLASTIC 281001368200
C530,C532 0.082uF J 50V PEI T CAP PLASTIC 281001382300
C205 820PF J 100V PPN T CAP PLASTIC 281201382100
C507 0.0039uF J 630V PPN 10 CAP PLASTIC 281204139200
C506 0.0062uF J 1.6KV PPS 25 CAP PLASTIC 281308162200
C523 0.00022uF 2KV PPS J 15 CAP PLASTIC 281309122100
C524 0.033uF J 250V MEF 10 CAP PLASTIC 281405133300
C220 0.15uF J 63V MEB T CAP PLASTIC 281502315400
C203,C304,C512 0.22uF J 63V MEB T (5%) CAP PLASTIC 281502322400
C219 0.47uF J 63V MEB T CAP PLASTIC 281502347400
C538 1.2uF J 250V MPP 20 CAP PLASTIC 281602112500
C535 0.22uF J 250V MPP 15 CAP PLASTIC 281602122400
C536 0.39uF J 250V MPP 20 CAP PLASTIC 281602139400
C534 0.33uF J 400V MPP 20 CAP PLASTIC 281603133400
C601 0.22uF AC 250V/300V 22.5 CAP X 291000022400
C610,C615 4700PF AC 250V (AH) CAP Y1 291250047200
L505 0A 6uH ET19 LINEARITY COIL 321000002300
L507 17uH COIL CHOKE 321200001300
L510 3mH COIL CHOKE 321200003500
L602 35mH AC LINE FILTER 321300100700
G2B 1-T-20x10x10-EM2 CORE 321500002300
L608 6mmX10mm COIL BEAD 321503000400
J05,L102,L501,L502, 3.5mmX6mm COIL BEAD 321503001000
L603,L606,L609,L610,
L612
J28,J28A,L503 3.5X9X0.8 CORE BEAD 321503001300
L601,L601A 35uH CORE RING 321700001000
D202 10uH K T (EC24) COIL PEAKING 323053010000
T601 POWER UD1 TRANSFORMER 331000002000
T501 FBT ET17 TRANSFORMER 331100002300
T504 FOCUS TRANSFORMER 331250000600
T503 COUPLING TRANSFORMER 331250000700
T502 L:53uH+/-20%,LK:160uH TRANSFORMER H-DRIVER 331300000800
Q608 2SA673AC TRANSISTOR 361103067300
Q201,Q503,Q506,Q515 2SA733P TRANSISTOR 361103073300
Q610,Q611 2SA1020Y T TRANSISTOR 361103102000
Q508 2SC5387(HFE) TRANSISTOR 361300538700
Q101,Q202,Q203,Q204, H945P / C945P TRANSISTOR TAPING 361303094500
Q504,Q511,Q514,Q523,
Q524,Q525,Q527,Q603,
Q606,Q607
