Elo TouchSystems ET1587C User Manual

- 192 -
Q609 2SC1213AC T TRANSISTOR 361303121300
Q507 2SK941 TRANSISTOR 361500094100
Q501 SSS6N60A TRANSISTOR 361550066000
Q602 SSS7N80A TRANSISTOR 361550078000
Q513 BF420 T TRANSISTOR 361603042000
Q502 BF423 T TRANSISTOR 361603042300
Q517,Q518 IRFS640A TRANSISTOR 361700064000
Q516 IRFS740B 10A/400V TO220F
TRS. N-MOSFET FAIRCHILD
361700074000
D502,D508 1A/600V 50-75ns T DIODE UF4005G JIT 371203100600
D619,D619B 1A/1000V 50-75ns T DIODE UF4007 JIT 371213101000
D101,D102,D204,D503, 1N4148(1A/75V) T DIODE 371303107500
D505,D507,D512,D610,
D613,D618
D509 UGP20G/SF20GG KINK P=20 DIODE (2A/400V) 371721200400
Q509 BY329X-1500S 5A/1500V DIODE 371960501504
D201,D513,D612,D801 FR102/PR1002 DIODE 1A/100V T 372153100100
D516,D611 FR104/PR1004 DIODE 1A/400V T 372153100400
D609 PR1005 DIODE 1A/600V T 372153100600
D301 FR107/PR1007 DIODE 1A/1KV T 372153101000
D617 HER304 3A/300V KINK P=20 DIODE 372201300325
D615 HER305 3A/400V KINK P=20 DIODE 372201300425
D621 UF3006 DIODE 3A/800V KINK P=20 372201300824
D622 UF3007 DIODE 3A/1KV KINK P=20 372201301024
D517 HER102/UF1002 DIODE 1A/100V T 372203100100
D616,D624 HER205/UF2004 DIODE 2A/400V T 372203200400
D608 HER207/UF2006 DIODE 2A/800V T 372203200800
D601 PBL406/KBL406(4A/800V) DIODE BRIDGE 373000400800
LED1 D=3mm GREEN L-34GD LED 373502100300
D605 1/2W HZ4C3 DO-35 T DIODE ZENER HITACHI 375003043300
D610A,R804 1/2W HZ5C2 5.0V-5.2V T DIODE ZENER 375003053200
D510 1/2W HZ15-2 T DIODE ZENER 375003150200
D619A 1/2W HZ20-3 20.2-21.1 T DIODE ZENER 375003200300
D515 1/2W HZ36-2 T DIODE ZENER 375003360200
D504 1W Z150A 150V 10% T ZENER DIODE 375503015100
U301 TDA8172 vertical process IC 381300017210
U201 TDA9113 IC 381400011310
U602 UC3842AM 8 IC 382500084227
U501 HA17812 3 IC 382600081201
Q505 TL431 IC 382660043144
U603 LM2940 3 IC 382700094005
U102 AT24C04 8 IC 384300040425
U103 WT6804 16 IC 384300080416
U101 VER02 ET1988C SEGA,TPS OTP/MTP MCU WT62P1
6AC0H
384900050075
RL501 AJS-1311 NAIS RELAY 1P2T 12V JS1-12V 432001200700
RL601 2P1T 12V FTR-F4AK012T RELAY 432002101000
