Symmetrix DMX-3 Specifications
International power
specifications
Table 51 on page 274 describes the electrical specifications for the
Symmetrix DMX-3 system bay and storage bays for systems installed
in international, three-phase, five-wire (WYE) environments.
International
extension cords
and mating
connectors
Each DMX-3 system bay and storage bay has two power cables
affixed to each PDP shown in Figure 61 on page 270. For an
international, three-phase, WYE configuration, attached to each PDP
is a 32A ABL Sursum S52.30 connector. Table 52 on page 274
describes the optional extension cords that connect to the ABL
Sursum S52.30 connectors.
Table 51 Electrical specifications, international, three-phase, five-wire, (WYE)
Specification International three-phase (WYE)
Input nominal voltage
a
200–240 VAC L-N nom (240 VAC optimal)
Range 200
–240 VAC + 10%
Frequency 50
–60 Hz
Circuit breakers 32 A
b
Power zones Two
Power requirements at customer site Two 32 A, three-phase drops per bay
a. An imbalance of AC input currents may exist on the three-phase power source feeding the Symmetrix system, depending on configuration.
The customer's electrician must be alerted to this possible condition to balance the phase-by-phase loading conditions within the customer's
data center.
b. For high voltage installations (380 - 415 VAC line-to-line), a 32 A rated circuit breaker is recommended. For international installations where a
three-phase, four-wire Delta source is used, a 50 A circuit breaker is required.
Table 52 Extension line cord, international, three-phase, five-wire, (WYE)
Extension line cord description Extension line cord
Mating connector
vendor part number
Three-phase, 15 ft line cord set, international IEC309 (WYE).
• Connector ABL Sursum K52.30 mates to the DMX-3 system bay
or storage bay power cord connector ABL Sursum S52.30.
• Flying leads on the other end of cable.
EMC model number:
DMX3-PC3YAFLE
(Figure 65 on page 275)
Flying leads. No mating
connectors available.
Three-phase, 15 ft line cord set, international IEC309 (WYE).
• Connector ABL Sursum K52.30 mates to the DMX-3 system bay
or storage bay power cord connector ABL Sursum S52.30.
• Connector, Garo P432-6 on the other end of cable connects to a
customer-supplied Garo S-432-6 coupler or equivalent.
EMC model number:
DMX3-PCBL3YAG
(Figure 66 on page 275)
Customer-supplied Garo
S-432-6 coupler or equivalent.
No EMC model available.
