Channel, disk, and global memory directors
77
Symmetrix DMX-3 Hardware
Fibre Channel
directors (front-end)
The Fibre Channel front-end director has eight FC ANSI compliant,
4 Gb/s (also configurable to 2 Gb/s, and 1 Gb/s) Fibre Channel
interfaces for connection to host systems. The director has eight
high-speed paths to global memory. The Fibre Channel director
interfaces to the host channels through an eight-port Fibre Channel
interface adapter and is available in single-mode and multimode
configurations (Table 17 on page 77). Each Symmetrix DMX Fibre
Channel director supports eight internal links to global memory. Data
transfers between host and global memory can execute concurrently
across all Fibre Channel ports on a director. Table 18 on page 78 lists
Table 17 Symmetrix DMX-3 channel director models and descriptions
Model number
Description
a
Fibre
Channel
b
GigE FICON
MM SM MM MM SM
DMX3-80000B 8-port Fibre Channel (FC) Director (8 MM ports) 8
DMX3-71000B 8-port Fibre Channel Director (7 MM /1 SM port) 7 1
DMX3-62000B 8-port Fibre Channel Director (6 MM/2 SM ports) 6 2
DMX3-00004B 4-port FICON Channel Director (4 SM ports) 4
DMX3-00040B 4-port FICON Channel Director (4 MM ports) 4
DMX3-00103B 4-port MPCD
c
(1 GigE or iSCSI MM port/3 FICON SM ports) 1 3
DMX3-00400 4-port GigE or iSCSI Channel Director (4 MM ports) 4
DMX3-ESCD8 8-port ESCON DIR (8 MM ports) N/A N/A N/A N/A N/A
DMX3-40002B 6-port MPCD (4 FC MM. port/2 FICON SM ports) 4 2
DMX3-40200B 6-port MPCD (4 FC MM. ports/2 GigE or iSCSI MM ports) 4 2
DMX3-60100B 7-port MPCD (6 FC MM. ports/1 GigE or iSCSI MM ports) 6 1
DMX3-00103BS 4-port MPCD (1 GigE IPv4/v6 (IPsec capable) MM port/ 3 FICON SM
ports)
13
DMX3-00400S 4-port GigE or iSCSI Channel Director (4 GigE IPv4/v6
(IPsec capable) MM ports)
4
DMX3-40200BS 6-port MPCD (4 FC MM ports/ 2 GigE IPv4/v6 (IPsec capable) MM
ports)
42
DMX3-60100BS 7-port MPCD (6 FC MM ports/ 1 GigE IPv4/v6 (IPsec capable) MM
port)
61
a. Contact your local EMC Sales Representative for currently supported host channel directors and GigE remote directors.
b. MM = multimode. SM = single-mode.
c. MPCD = Multiprotocol Channel Director.
