Disk-array enclosures
EMC VNX8000 Hardware Information Guide 115
As shown in Figure 96 on page 114, an enclosure ID
16
indicator is located on each ICM.
Each ICM also includes a bus (back-end port) identification indicator. The SP initializes
the bus ID when the operating system is loaded.
Table 48 describes the ICM status LEDs.
ICM input/output ports and connectors
The 4U, 60 DAE ICM supports the following I/O ports on the rear:
◆ Four 6-Gb/s PCI Gen 2 mini-SAS ports
◆ One management (RJ-12) connector to the SPS
◆ One USB connector
6-Gb/s mini-SAS x8 ports — The DAE ICM supports four (two input and two output) 6-Gb/s
mini-SAS x8 ports on the rear of each ICM (A and B). This port provides an interface for
SAS and NL-SAS drives in the DAE. The port is a 26-circuit mini-SAS small form-factor
8088 (SFF-8088) specification (socket or receptacle) using an SFF-8088 specification
mini-SAS 26-circuit cable (plug) with a pull tab.
Note: Each SAS cable is keyed with an
in
and
out
connection to prevent incorrect cabling.
A video describing how to properly connect mini-SAS HD cables and mini-SAS cables to a
DPE and a DAE, respectively, in a VNX product is available online at:
https://edutube.emc.com/, in the Search box, type in Mini-SAS HD Cable Connectivity.
The video will start immediately.
Note: The first half of the video shows an example of how to connect a mini-SAS HD cable
to a mini-SAS HD port while the second half shows how to connect a mini-SAS cable to a
DAE LCC port.
16. The enclosure ID is sometimes referred to as the enclosure address (EA).
Table 48 ICM status LEDs
Led Color State Description
Power on Green On Power on
—OffPower off
Power fault Amber On Fault
— Off No fault or power off
