12 EMC VNX8000 Hardware Information Guide
VNX8000 product description
• On the rear, the VNX8000 has from one to four DMEs having two to eight Data
Movers (DMs). Each DM consists of:
– One management module (see “Data Mover management module” on page 42
for more information) featuring:
a.) One RS-232/EIA 232 serial (up to 115 K baud) service laptop (micro DB-9)
port
b.) Three 10/100/1000 LAN network management (RJ-45) ports
Note: The management module is secured with a latch handle (labeled MGMT).
– One CPU module consisting of one Intel Xeon 6-core 2.8-GHz processor. The
CPU modules in the DME contain the power, fault, and unsafe-to-remove LEDs
(see “CPU” on page 25 for more information).
– Six DDR3 synchronous dynamic RAM (SDRAM) slots supporting up to 24 GB per
CPU module using 2 or 4 GB DIMMs
– Five PCI Gen 2, 8x lane I/O module slots (0 – 4) available for use, supporting:
Note: The maximum number of I/O modules for the VNX8000 is five per DM. One
FC I/O module and up to three other I/O modules. Any combination of these I/O
modules must be the same for both Data Movers.
a.) One Fibre Channel (FC) I/O module with a:
– Four-port 8-Gb/s optical (running at 2, 4, or 8 Gb/s); in slots A0 and B0
only; labeled 8 GbE Fibre on the latch handle
b.) One or two of the following network I/O modules in any combination:
– Two-port 10-Gb/s optical or active Twinax; labeled 10 GbE v3 on the
latch handle
– Four-port 1-Gb/s copper; labeled 1 GbE on the latch handle
– Two-port 10-Gb/s RJ45 Base-T iSCSI/IP; labeled 10 GbE Base-T on the
latch handle
◆ One to two 1U Control Stations
◆ Expansion of up to sixty 2U, 25 DAEs (a maximum of 1,500 2.5-inch disk drives), of up
to on-hundred 3U, 15 DAEs (a maximum of 1,500 2.5- or 3.5-inch disk drives), up
twelve 3U, 120 DAEs (a maximum of 1,440 2.5-inch disk drives), or up to twenty-five
4U, 60 DAEs (a maximum of 1,500 2.5- or 3.5-inch disk drives) is supported.
◆ Any required cables including LAN cables, modem cables, and serial DB-9 cable.
◆ Mounting rails with hardware
◆ Front bezel with VNX8000 badge
