EMC VNX Series

124 EMC VNX8000 Hardware Information Guide
Disk-array enclosures
Note: If the 4U, 60 (2.5- or 3.5-inch) DAE does not slide out of the rack (or cabinet) far
enough for you to access the internal components and lock on the rails in the service
position, verify that all the other DAEs are completely seated in the rack (or cabinet) by
pushing firmly on them.
Figure 105 shows an example of a 4U, 60 (2.5- or 3.5-inch) DAE with the top cover closed.
Figure 105 4U, 60 (2.5- or 3.5-inch) DAE (with top cover closed)
Figure 106 shows an example of a 4U DAE with the top cover open showing the disk
drives, LCCs, and the cooling modules or fans.
Figure 106 4U, 60 (2.5- or 3.5-inch) DAE (with top cover open)
Top cover
VNX-000656
Top cover
VNX-000649
