DPSI BMS Operating Manual Version 1.0
Page 16 of 32
9. Initial Operation
Initial operation, On/Off, Status Display:
The DPSI BMS is simply put in between battery and consumer (e.g.
between two LongGo batteries and a DPSI RV system).
Turning On/Off can take place in two different ways:
- Automatically turning On/Off
- Manually turning On/Off
9.1. Automatically Switching On/Off
Automatically turning on of the DPSI BMS always works. As soon as
the connected consumer (e.g. a receiver set connected to a battery
switch) draws current from battery 1 which exceeds approx. 100 to 150
milli amps, the DPSI BMS turns on automatically. Current drawn by a
receiver set using several servos usually clearly exceeds more than
150 milli amps per battery.
