DPSI BMS Operating Manual Version 1.0
Page 6 of 32
Summary:
The DPSI BMS allows for full control of two independent batteries. This
means:
Two independent batteries connectable (galvanically
separated)
Two 12 bit A/D converters for high precision data
acquisition
Automatic On/Off switching; therefore only single
switch necessary
LC-Display with indication of voltage, current, capacity,
operating time of each battery or both batteries together
with min./max.- and average values
1 channel version and 2 channel version available
3. Properties of the DPSI BMS
Displaying system for two separate batteries in battery switches or
other applications
Easily fitted between battery and consumer
Discharges the battery with only 10 µA in turned off state
Automatically switches On/Off without additional switch
2-4 cell LiIon / LiPo batteries usable
5-12 cell NiCad / NiMH batteries connectable
Up to 10A constant current per channel permissible
Up to 30A peak current durable
Programmable user language (German / English)
Wireless system, i.e. all leads is pluggable and therefore
exchangeable at any time
High-quality plastic housing including bracket for the battery
connectors
